Fax Settings
 Check Point / チェックポイント |
|
Setting Method
Port 1 settings: [Setting]
[General Settings][Fax Settings][Basic Settings (Ch1)]
List of Basic Fax Settings
Default Value | G3-1 (LINE1) | Remarks | |
|---|---|---|---|
[Fax Settings] > [Basic settings] | |||
Communication mode | 33.6 kbps (Super G3) | 33.6 kbps (Super G3) 14.4 kbps (G3) 9.6 kbps (G3) | For an optical line, "33.6 kbps (Super G3)" may cause a communication error. |
Error correction (ECM) | ON | OFF ON | Normally used with “ON”. |
Dial tone detection | On | OFF ON | Set according to phone line type or services. |
Dial type | Push | Push Dial (20 PPS) Dial (10 PPS) | |
Number display support | OFF | OFF ON External phone priority | |
Connection Line | PSTN | General line (PSTN) Private branch exchange (PBX) | |
Source name | Registering a sender name | Registering a sender name | |
Source name | Registering a sender name | Registering a sender name | |
Receive mode | Auto | Auto Automatic fax telephone switching Manual | |
Number of calls | 1 | 0 to 15 | All "1" in the case of the representative set of the subscribed telephone line. In case of optical line / ISDN, change according to the incoming call priority. |
Number of phone calls | 8 | 3 - 15 | |
Remote reception | OFF | OFF On | |
Call rejection | OFF | OFF On | |
Fax Rejection | OFF | OFF On | |
File format for saving / transferring | TIFF | ||
Communication settings for each line | Send / Receive | Send / Receive Send only Receive only | Normally, it is used for both transmission and reception. Select "Receive Only" for the port that you want to use to receive only without sending. The port that you want to use only for transmission without receiving is set on the line side. |
| Cloud address list | |||
| Additional line settings (IP fax) |
